Rolectro
Maximus
-E-scooter MX3-25 -
| Technical data | |
|---|---|
| Top speed | about 25 km/h |
| Motor | 1500 watts/60V, rear wheel hub motor |
| circuit | Automatically |
| battery pack | 60V/32.5 Ah, lithium battery, removable |
| Battery box weight | 14 kg |
| Charging cycles | 700-800 |
| Loading time | 6-8 hours |
| Range | approx. 70km, depending on topography, load, tire pressure etc. |
| climbing ability | 6.84 Grad (12%) |
| Brake system | Disc brake at the front, drum brake at the rear |
| Frame | Tubular steel frame |
| tires | 90/90-12" (front and rear), tubeless, air pressure 2.5 bar (36 PSI), wheel diameter: 41cm |
| suspension | Damped telescopic fork at the front, 2 shock absorbers at the rear |
| Wheel diameter | 41 cm |
| lighting | E-Mark certified, LED low beam and high beam, LED brake and tail light, LED indicators |
| Cockpit/ Tacho | Speed display, battery charge indicator, light and indicator symbols, total mileage display, battery charge indicator, light and indicator symbols, total mileage display |
| further equipment | USB charging socket 5V/1A, digital speedometer, top case, 2x ignition key, alarm system with 2x remote control, windshield |
| Color | Rot/Schwarz |
| Seat | Bench |
| Own weight including battery | 114 kg |
| maximum weight allowed | 294 kg |
| payload | 180 kg |
| Seat height | 865 mm, passenger: 890 mm |
| Dimensions assembled (LxWxH) | 2125 x 715 x 1340 mm |
| Permit | for 2 people, EU operating license (EEC) |
| Accesories | Charger, 2x mirrors, top case, mobile phone holder manual, EEC document |
Legal regulations and
General information
Helmet requirement
If you wear a safety belt, you are not required to wear a helmet.
If the Maximus MX3-25 is driven without a belt fastened,
Helmets are required.
Liability insurance
Electric vehicles require insurance and license plates!
When you take out this insurance you will receive an insurance number,
that must be attached to the vehicle.
An operating license is included with the scooter.
Driver's license
A license to drive mopeds is required to operate.
Minimum age 15 years. Holders of driving license categories A, B and T
do not require a permit.
People born before April 1, 1965
do not require a permit or driver's license.
Where can you drive the vehicle?
The use of public footpaths and cycle paths (in town) is not permitted.
Cycle paths may be used in urban areas,
which are marked with a moped on the traffic sign.
Cycle paths may be used outside built-up areas.
Furnishing
- 1500 watt motor
- LED headlights at the front
- LED taillight
- Digital, easy-to-read display
- removable lithium battery
- Rear shock absorber
- Windshield
- Alarm system
- USB charging socket
- Rear drum brake
- Front disc brake
scope of delivery
- 1x Maximus MX3-25
- 1x EEC (road legal)
- 1x charger
- 1x lithium battery
- 2x mirror
- 1x operating instructions (German)
- 1x top case
- 1x windshield
- 1x cell phone holder
